RM-2443WS-3G2
Quad 4.3-Inch Widescreen LCD Video Monitor
Photo 1 of 2What it does
The RM Series is a full-featured, low-cost range of in-rack 3G/HD/SD-SDI and CVBS video monitors ideal for the many feeds in mobile trucks, news and transmission control rooms, duplication, and post production applications. These tilting monitors come standard with in-monitor level metering, selectable video waveform and vectorscope, safe and title markers, labeling, tally, timecode, video format, and built-in color bars, as well as familiar CRT-style picture controls and an intuitive on-screen configuration menu. Input signals are automatically detected and up to 8 of the 16 audio channels embedded in an HD/SD-SDI bitstream may be selected for visual monitoring on 8 on-screen bar graph style level meters on the 3G and 3G2 models. A headphone jack provides audible stereo monitoring of selected left and right channels. Each of the four high-resolution LCD screens display high-definition or standard-definition video at either 16:9 or 4:3 aspect ratio. Parameters are selected and adjusted using an on-screen display menu.
Datasheets, manuals & software
Datasheet
Capabilities
- Hybrid SDI/IP
- 24/7 operation
Why it's trusted
On-screen level meters provide confidence audio monitoring.
Tally and on-screen labeling provide quick and easy signal identification
CRT-style image controls allow video image enhancement for each screen individually
User defined hot key functionality provides either H/V delay, underscan, on-screen display, and more
In-picture waveform, and vectorscope display
Labelling, tally, timecode, detected video format, safe area and title markers display
On-screen image calibration controls
Gamma color calibration
Built-in color bars
User-defined function buttons
Intuitive on-screen menu
Specifications
- Rack Height
- 2RU
- Meter Dynamics
- VU or PPM or both
- Number of screens
- 4
- Power Consumption
- 10 Watts (3.8 Amps Max)
- Power Supply
- External 12VDC/3.8A, CE & UL approved.
- Dimensions
- 19.0″ (483mm) x 3.5″ (89mm) x 2.5″ (64mm)
- Net/Shipping Weight
- 7.0 lbs (3.2 kg) / 7.0 lbs (3.2 kg)
- Shipping Dimensions
- 24.0 × 10.0 × 6.0 in (LxWxH)
